Hydraulic Filter, Cartridge Dt - Donaldson P566698

Attributes

• Seal Material: Viton
• Outer Diameter: 69.8 mm (2.75 inch)
• Inner Diameter: 34 mm (1.34 inch)
• Overall Length: 355.1 mm (13.98 inch)
• Efficiency Beta 1000: 5 micron
• Collapse Burst: 207 bar (3002 psi)
• Style: Cartridge
• Brand: DT High-Performance
• Media Type: Synthetic

Packaged Dimensions

• Packaged Length: 0.433 m (17.32 inch)
• Packaged Width: 0.099 m (3.94 inch)
• Packaged Height: 0.099 m (3.94 inch)
• Packaged Weight: 1.280 kg (2.82 lb)
• Packaged Volume: 0.004 m3 (0.16 ft3)

Other Information

• Country of Origin: United States
• NMFC Code: 069100-10
• HTS Code: 8421298090
• UPC Code: 742330179604
