Hydraulic Filter, Cartridge Dt - Donaldson P566375
Hydraulic Filter, Cartridge Dt - Donaldson P566375
Regular price
Ā£99.44
Regular price
Sale price
Ā£99.44
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Donaldson P566375
Hydraulic Filter, Cartridge Dt| Seal Material | Viton |
| Outer Diameter | 3.2 inch (81.2 mm) |
| Inner Diameter | 2.01 inch (51.1 mm) |
| Overall Length | 7.95 inch (201.9 mm) |
| Efficiency Beta 1000 | 12 micron |
| Collapse Burst | 149 psi (10.3 bar) |
| Style | Cartridge |
| Brand | DT High-Performance |
| Media Type | Synthetic |
Share
Collapsible content
Specifications
Attributes
- Seal Material: Viton
- Outer Diameter: 81.2 mm (3.2 inch)
- Inner Diameter: 51.1 mm (2.01 inch)
- Overall Length: 201.9 mm (7.95 inch)
- Efficiency Beta 1000: 12 micron
- Collapse Burst: 10.3 bar (149 psi)
- Style: Cartridge
- Brand: DT High-Performance
- Media Type: Synthetic
Packaged Dimensions
- Packaged Length: 0.227 m (9.06 inch)
- Packaged Width: 0.099 m (3.94 inch)
- Packaged Height: 0.099 m (3.94 inch)
- Packaged Weight: 0.295 kg (0.65 lb)
- Packaged Volume: 0.002 m3 (0.08 ft3)
Other Information
- Country of Origin: United States
- NMFC Code: 069100-06
- HTS Code: 8421298090
- UPC Code: 742330176641
Cross Reference
| Manufacturer Name | Manufacturer Part Number | Notes |
|---|---|---|
| PTI | PC96030KFB | |
| PTI | PC96030KFV |
