Head Assembly, Fuel - Donaldson P562263

Attributes

• Length: 83 mm (3.27 inch)
• Width: 83 mm (3.27 inch)
• Height: 62 mm (2.44 inch)
• Inlet Size: 1/2-20 UN
• Outlet Size: 1/2-20 UN
• Filter-to-Head Thread: M16 x 1.5
• Bypass Valve: No

Packaged Dimensions

• Packaged Length: 0.098 m (3.90 inch)
• Packaged Width: 0.100 m (4.00 inch)
• Packaged Height: 0.145 m (5.80 inch)
• Packaged Weight: 0.272 kg (0.60 lb)
• Packaged Volume: 0.001 m3 (0.05 ft3)

Other Information

• Country of Origin: Mexico
• NMFC Code: 133320
• HTS Code: 8421999099
• UPC Code: 742330143803
